PPF-50T HUALIAN volumetric piston filler for paste
Description:
PPF series paste piston fillers are designed for filling products at any kinds of ropy pitch from aquiform to viscosity.
Application:
PPF series paste piston filler is best suited for medicine, chemistry, lube and daily merchandise etc.
Parameters:
| PPF-50 | PPF-50T | PPF-250 | PPF-250T | PPF-500 | PPF-500T | PPF-1000 | PPF-1000T | PPF-2000 | PPF-2000T |
Voltage (V/Hz) | AC 220/50 or 110/60 | |||||||||
Power (W) | 20 | |||||||||
Gas Pressure (Mpa) | 0.4-0.6 | |||||||||
Filling Range (ml) | 5-50 | 5-50 | 50-250 | 50-250 | 100-500 | 100-500 | 200-1000 | 200-1000 | 300-2000 | 300-2000 |
Filling Capacity | 10-18 | |||||||||
Filling Accuracy | ≤1% | |||||||||
External Dimensions (L×W×H) (cm) | 90X50X105 | 77X25X78 | 90X50X105 | 77X25X78 | 100X50X105 | 88X25X77 | 110X50X105 | 101X25X77 | 112X50X105 | 112X25X77 |
Net Weight (kg) | 31 | 26.5 | 30 | 25.5 | 35 | 27 | 40 | 32 | 43 | 35 |
